Intel Core i7-14700 LGA1700 2.1GHz 20-Core Processor

Description

Experience next-level desktop performance with the Intel Core i7-14700 LGA1700 2.1GHz 20-Core Processor – engineered to accelerate gaming, content creation, and demanding multitasking workloads. Built on Intel’s innovative 14th Gen hybrid architecture, this high-performance CPU features a significant increase in core count, intelligently combining Performance-cores (P-cores) and Efficient-cores (E-cores) to deliver optimal responsiveness across diverse applications.
Designed for power users, creators, and competitive gamers, the Intel Core i7-14700 supports up to 16 PCIe 5.0 lanes and lightning-fast DDR5 memory at speeds of up to 5600 MT/s, ensuring future-proof bandwidth for next-gen GPUs and storage. Intel Turbo Boost Max Technology 3.0 enhances lightly threaded workloads by prioritising the most efficient cores, while expanded L2 and L3 Smart Cache enables faster access to larger datasets and seamless multitasking across applications.
The processor also supports up to four 4K@60Hz displays or a single 8K@60Hz HDR output, delivering stunning visual clarity for immersive gaming and productivity. With comprehensive support for Intel 700 series chipsets and backward compatibility with 600 series motherboards, including B760, Z790, and H610 motherboards. This broad compatibility empowers builders to select the ideal platform for any application or budget.
Whether you are pushing creative boundaries, conquering the latest AAA titles, or managing intensive workflows, the Intel Core i7-14700 is the performance powerhouse for the modern desktop environment.
FEATURES:

20 Cores and 28 Threads: Optimised for multitasking and high-performance computing
Max Turbo Frequency of 5.4 GHz: Delivers swift and responsive processing speeds
Intel UHD Graphics 770: Supports high-resolution displays up to 7680 x 4320 at 60Hz
Supports DDR5 and DDR4 Memory: Compatible with up to DDR5 5600 MT/s and DDR4 3200 MT/s memory types
PCIe 5.0 and 4.0 Support: Offers up to 20 PCI Express lanes for high-speed data transfer
Intel Turbo Boost Max Technology 3.0: Enhances performance by identifying and boosting the fastest cores
Efficient Thermal Design: Operates with a Processor Base Power of 65 W and Maximum Turbo Power of 219 W

SPECIFICATIONS:

Essentials:
Product Collection: Intel Core i7 Processors (14th gen)
Code Name: Products formerly Raptor Lake
Vertical Segment: Desktop
Processor Number: i7-14700
Lithography: Intel 7
CPU Specifications:
Total Cores: 20
# of Performance-cores: 8
# of Efficient-cores: 12
Total Threads: 28
Max Turbo Frequency: 5.4GHz
Intel Turbo Boost Max Technology 3.0 Frequency: 5.4GHz
Performance-core Max Turbo Frequency: 5.3GHz
Efficient-core Max Turbo Frequency: 4.2GHz
Performance-core Base Frequency: 2.1GHz
Efficient-core Base Frequency: 1.5GHz
Cache: 33 MB Intel Smart Cache
Total L2 Cache: 28 MB
Processor Base Power: 65 W
Maximum Turbo Power: 219 W
Memory Specifications:
Max Memory Size (dependent on memory type): 192 GB
Memory Types:

Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s

Max # of Memory Channels: 2
Max Memory Bandwidth: 89.6 GB/s
ECC Memory Supported: Yes
GPU Specifications:
GPU Name: Intel UHD Graphics 770
Graphics Base Frequency: 300MHz
Graphics Max Dynamic Frequency: 1.6 GHz
Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units: 32
Max Resolution (HDMI): 4096 x 2160 @ 60Hz
Max Resolution (DP): 7680 x 4320 @ 60Hz
Max Resolution (eDP – Integrated Flat Panel): 5120 x 3200 @ 120Hz
DirectX* Support: 12
OpenGL* Support: 4.5
OpenCL* Support: 3.0
Multi-Format Codec Engines: 2
Intel Quick Sync Video: Yes
Intel Clear Video HD Technology: Yes
# of Displays Supported: 4
Device ID: 0xA780
Expansion Options:
Direct Media Interface (DMI) Revision: 4.0
Max # of DMI Lanes: 8
Scalability: 1S Only
PCI Express Revision: 5.0 and 4.0
PCI Express Configurations: Up to 1×16+4, 2×8+4
Max # of PCI Express Lanes: 20
Package Specifications:
Sockets Supported: FCLGA1700
Max CPU Configuration: 1
Thermal Solution Specification: PCG 2020C
TJUNCTION: 100°C
Package Size: 45.0 mm x 37.5 mm
Max Operating Temperature: 100 °C
Advanced Features:
Intel Volume Management Device (VMD): Yes
Intel Gaussian & Neural Accelerator: 3.0
Intel Thread Director: Yes
Intel Deep Learning Boost (Intel DL Boost): Yes
Intel Speed Shift Technology: Yes
Intel Turbo Boost Max Technology 3.0: Yes
Intel Turbo Boost Technology: 2.0
Intel Hyper-Threading Technology: Yes
Intel 64: Yes
Instruction Set: 64-bit
Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States: Yes
Enhanced Intel SpeedStep Technology: Yes
Thermal Monitoring Technologies: Yes
Security & Reliability
Intel vPro Eligibility: Intel vPro Enterprise, Intel vPro Essentials, Intel vPro Platform
Intel Hardware Shield Eligibility: Yes
Intel Threat Detection Technology (TDT): Yes
Intel Active Management Technology (AMT): Yes
Intel Standard Manageability (ISM): Yes
Intel Remote Platform Erase (RPE): Yes
Intel One-Click Recovery: Yes
Intel Control-Flow Enforcement Technology: Yes
Intel Total Memory Encryption – Multi Key: Yes
Intel AES New Instructions: Yes
Secure Key: Yes
Intel OS Guard: Yes
Intel Trusted Execution Technology: Yes
Execute Disable Bit: Yes
Intel Boot Guard: Yes
Mode-based Execute Control (MBEC): Yes
Intel Stable IT Platform Program (SIPP): Yes
Intel Virtualization Technology with Redirect Protection (VT-rp): Yes
Intel Virtualization Technology (VT-x): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel VT-x with Extended Page Tables (EPT): Yes

WHAT’S IN THE BOX:

Intel Core i7-14700 LGA1700 2.1GHz 20-Core Processor x1
